The P600 Pro Mixer Console Bluetooth Pairing feature allows you to wirelessly connect your devices for seamless audio streaming. Whether you’re a podcaster, streamer, or musician, this functionality enhances your setup by eliminating the need for physical connections.
How to Pair Your P600 Pro Mixer Console via Bluetooth
Step 1: Connect the Power Adapter
Ensure the power adapter is properly connected to the mixer. Align the concave on the adapter with the bulge on the socket to prevent damage. Avoid forcing the connection.
Step 2: Activate Bluetooth/USB Mode
Locate the switch beneath channels 5/6. Press the switch down to enable Bluetooth/USB mode. Note: Channels 5 & 6 cannot be used simultaneously with Bluetooth. When the switch is pressed up, you can use all six output channels, including the fifth and sixth channels, as stereo inputs. When the switch is pressed down, you can use the first four channels and the Bluetooth/USB inputs.
Step 3: Power On the Mixer
Press the power switch near the power adapter. The display will show “No” by default.
Step 4: Enter Bluetooth Mode
Press the Mode button until “bLUE” flashes on the display, indicating that the mixer is ready for Bluetooth pairing.
Step 5: Pair with Your Device
On your smartphone or tablet, enable Bluetooth and search for available devices. Select “MIX MP3-BT“ from the list. Once connected, the “bLUE” display will stop flashing, confirming a successful connection.
Playback Controls on the Mixer
- P/P Button: Play/Pause music. Long press to toggle between repeat (“ONE”) and loop (“ALL”) modes.
- PREV Button: Short press for the previous track; long press to decrease volume.
- NEXT Button: Short press for the next track; long press to increase volume.
Important Notes
- Bluetooth and USB functions cannot operate simultaneously. Ensure only one is active at a time.
- Recording via Bluetooth is not supported. To record audio, use the USB or PC mode.
Frequently Asked Questions
1. Can I use channels 5 and 6 while Bluetooth is active?
No, channels 5 and 6 cannot be used simultaneously with Bluetooth. You must choose between using these channels or the Bluetooth function.
2. How do I control the volume during Bluetooth playback?
You can adjust the volume by long-pressing the NEXT button to increase volume or the PREV button to decrease volume.
3. Can I record audio while streaming via Bluetooth?
No, recording via Bluetooth is not supported. To record audio, use the USB or PC mode.
4. What should I do if the mixer doesn’t pair with my device?
Ensure that the mixer is in Bluetooth mode and that your device’s Bluetooth is enabled. If the issue persists, try restarting both devices and attempt the pairing process again.
